CNC NC automatic electric hydraulic horizontal busbar steel sheet metal cutting and bending press brake machine price for sale

control delem da41 press brake

Features of CNC press brake

Whole welding steel plate, the stress is eliminated by the vibration after tempering with high stability.
The CNC press brake features a hydraulic proportional valve to ensure that parts are produced efficiently and accurately.
With exceptional price/performance ratio.
Large open height allows deep box bending.
Fast multiple axis back gauge.

Standard configuration

Y1, Y2 magnetic scale positioning for high precision (+/-0.0004’’).
X axis precision ball screw back gauge (+/-0.0004’’).
4+3axis (Y1,Y2,X,R,Z1,Z2,+V crowning).
Easy slide linear guide mounted back gauge fingers.
Quick clamp.
Side and rear mounted doors with safety interlocks.
Pedestal mounted foot pedal up/down and emergency stop.
Dynamic crowning ( measures deflection and sends feedback to the computer to compensate )

Model	Nomal Pressure (kn)	Length of Table (mm)	Distance Between Housing (mm)	Throat Depth (mm)	Stroke (mm)	Open Hight (mm)	Main Motor (kw)	Overall Dimensions
40T/1300	400	1300	1000	250	160	400	4	183014302215
40T/1600	400	1600	1300	250	160	400	4	213014302215
40T/2000	400	2000	1500	250	160	400	4	253014302215
40T/2500	400	2500	2000	250	160	400	4	303014302215
63T/2000	630	2000	1500	320	160	400	5.5	254016402225
63T/2500	630	2500	2000	320	160	400	5.5	304016402225
63T/3200	630	3200	2660	320	160	400	5.5	3710x1650x2450
80T/2500	800	2500	2000	400	160	410	7.5	305016502305
80T/3200	800	3200	2660	400	160	410	7.5	371016502405
100T/2500	1000	2500	2000	400	200	450	7.5	306016902425
100T/3200	1000	3200	2660	400	200	450	7.5	372016902475
100T/4000	1000	4000	3200	400	200	450	7.5	450016902545
125T/2500	1250	2500	2000	400	200	450	7.5	308017602500
125T/3200	1250	3200	2660	400	200	450	7.5	374017602535
125T/4000	1250	4000	3200	400	200	450	7.5	452017602610
125T/6000	1250	6000	4800	400	200	450	7.5	610015002895
160T/2500	1600	2500	2000	400	200	470	11	310018302520
160T/3200	1600	3200	2660	400	200	470	11	376018302620
160T/4000	1600	4000	3200	400	200	470	11	454018302720
160T/6000	1600	6000	4800	400	200	470	11	610015703000
200T/3200	2000	3200	2660	400	200	470	11	376018802670
200T/4000	2000	4000	3200	400	200	470	11	454018802770
200T/6000	2000	6000	4800	400	200	470	11	6080x1950x2900
250T/3200	2500	3200	2660	400	250	490	15	378019802860
250T/4000	2500	4000	3200	400	250	490	15	4560x1980x2960
250T/5000	2500	5000	4000	400	250	490	15	5080x2100x3250
250T/6000	2500	6000	4800	400	250	490	15	6080x2200x3400
300T/3200	3000	3200	2660	400	250	500	22	380020803090
300T/4000	3000	4000	3200	400	250	500	22	458020803090
300T/5000	3000	5000	4000	400	250	500	22	5100x2200x3300
300T/6000	3000	6000	4800	400	250	500	22	660022503500
400T/4000	4000	4000	3200	400	300	605	30	458024603600
400T/5000	4000	5000	4000	400	300	605	30	560024603750
400T/6000	4000	6000	4800	400	300	605	30	6200x2650x4000
500T/4000	5000	4000	3200	600	300	615	37	4200x2800x4100
500T/5000	5000	5000	4000	600	300	615	37	5200x2800x4200
500T/6000	5000	6000	4800	600	300	615	37	6200x2800x4300
600T/5000	6000	5000	4000	600	300	650	37	5200x3000x4400
600T/6000	6000	6000	4800	600	300	650	37	6200x3000x5400
800T/5000	8000	5000	4000	700	350	710	55	520035005600
800T/6000	8000	6000	4800	700	350	710	55	620035005800
1000T/6000	10000	5000	4800	700	350	730	55	620035005800

Quick Details

Condition: New
Place of Origin: Jiangsu, China (Mainland)
Brand Name: ACCURL
Model Number: WEK 100T3200mm
Machine Type: Roller-Bending Machine
Raw Material: Sheet / Plate Rolling
Material / Metal Processed: Carbon Steel
Power: Cnc
Automation: Automatic
Extra Services: End Forming
Certification: CE
After-sales Service Provided: Engineers available to service machinery overseas
Name: WEK 100T3200mm CNC hydraulic press brake
Size: Customized
Color: Customized
Usage: Metal Sheet Bending
Application: Stainless Steel Plate, steel bar, steel plate Bending
Warranty: 13 month
Seal ring:NOK
Valve: USA, First
Punch and die: T7,T8,42CrMo
Control system: All brands available
