Hydraulic press brake plate bending machine MB7 100T 3200mm


ACCURL® Easy Bend B Series Hydraulic NC Press Brake Machine is our most popular model by volume and a true workhorse. The studies made on the framework flections have allowed us to design a product that reacts in the most appropriate and responsive way to the mechanical solicitations, therefore guaranteeing a stable structure, thus a higher precision in bending. This feature is even enhanced by a system of manual crowning. Worth mentioning is also the possibility to add options and upgrades on the configuration, at later stage.Constructed of high quality parts and offering serious reliability , Y-axis Torsion bar syncro technology with high approach, bending and return speeds.

ACCURL® Easy Bend B Series Hydraulic Torsion Bar Press Brakes are perfect for forming small parts with low operating costs and with Torsion bar syncro NC Two axis control capability they perform just like our bigger Press Brakes.

Defender
Defender is a press brake guarding system designed for retrofit applications and provides an economical solution for operator protection and machine productivity.

• Defender laser protection (CE Certified Category 4 Safety Controller)
• Two sides door-type safety guard and rear safety guard with rear door
• Doors equipped with electric safety switch
• Safety covers for inside and outside main cylinder
• Safety covers for front and back of CNC crowning system
• Often-use internal hexagonal key spanner for adjusting tools

Manual Crowning
To confirm a constant bend angle, pre-load the machine with manual crowning which will offset potential deviations and allow for possible tooling wear to maintain parallel contacting surfaces.Manual crowning requires the simple development of a chart or spreadsheet for each new application.Varying properties in material can caus different outcomes and calculations/setting may need to be adjusted accordingly.

• Uploading of DXF, DWG and IGES files
CONTROL FEATURES:
• Germany ELGO P40 NC Control
• 2 automatic axes: Y + X-Axis
• Standard BGA back gauge equipped with ball screws
• Sheet metal frontal supports,
• Front cover: Defender lazersafe (CE Certified Category 4 Safety Controller)
• Rear cover: Safety barriers (Category IV)
• Front and rear lighting
• Standby Function

Quick Details


Condition: New
Place of Origin: Anhui, China (Mainland)
Brand Name: AccurL
Machine Type: Press Brake
Raw Material: Sheet / Plate Rolling
Material / Metal Processed: Stainless Steel
Power: Cnc
Automation: Automatic
Extra Services: End Forming
Certification: CE
After-sales Service Provided: Engineers available to service machinery overseas
CNC Control system: DELEM DA41s CNC System
CNC Control Axis: Y X axis Crowning(Electro-hydraulic servo)
Electrical components: Schneider Electrical from French
Motor Power: Siemens from Germany
BackGauge & RAM Drive: Inverter from Schneider Electrical
Ball screw/ Polished rod: HIWIN from TaiWan Brand
Hydraulic System: Bosch-Rexroth from Germany
Tubing connector: EMB from Germany Brand
Servo motor/ Servo drive: YASKAWA from Japan Brand
Keyword: press brake

, , , , , , , ,
